Drum motors for pallet handling Series TP89
key word:
Category:
Pallet drive
样册下载：
Tel：
Email：
|
Three-phase asynchronous electric roller for tray conveying TP809 (Oil Free) |
|||||||||||
|
Model |
Power |
Rated Voltage[V]/ |
Working System |
Pole Number |
Gear Progression |
Gear Ratio |
Maximum Speed |
Torsion |
Load |
Rated Current[A] |
EL Value Range |
|
TP89 |
0.07 |
3*380V/50Hz |
S3 50% |
2 |
2 |
62.70 |
0.22 |
22 |
1250 |
0.35 |
500-1500mm |
|
0.07 |
3*220V/50Hz |
S3 50% |
2 |
2 |
62.70 |
0.22 |
22 |
1250 |
0.60 |
500-1500mm |
|
Additional specifications:
►Motor protection level: IP54
►Ambient temperature：-5 ℃ to +40 ℃
►Drive head： sprocket 5/8" Z15, Z18, or other sizes of sprockets are available, as well as timing belt pulleys.
►Cable with 6 cores : three-phase wire + ground wire + thermal protection wire.
